[anthemavm]

Originally Posted by Ptree1822

my 20's 811m, m sport springs. 245/35/20, 275/30/20

Are the 811m staggered or square set up?

[Ptree1822]

Originally Posted by anthemavm

Are the 811m staggered or square set up?

staggered

[540iSUP]

Originally Posted by anthemavm

That looks sharp, what offset?

20 x 9.5 +28 front
20 x 10.5 +38 rear

Tires are
245/35/20 front
275/30/20 rear

Tires are a little too stretched for me so I'm thinking 265 in front and maybe a 285 or 295 rear.

[jag81]

https://photos.app.goo.gl/cUWHHAf9j9vjRYU28

[G30M]

Originally Posted by DerekS

Here's my 2021 540ix with 20" Style 846M alloys and Pirelli P Zero RFTs.
I will be selling this wheel/tire set soon.

i have these and they look better in real life than the pics, and then just when you thought they looked amazing, they look even better with a coat of road dust after a drive! madness

wondering if you have weighed the wheel-tire combos? or know the rim weight? interweb not very useful here

thanks

[One800GetSome]

Originally Posted by Alpine540iM

Lowered on h&r with oem 20" wheels

Any rubbing issues?

[AntWrig]

Originally Posted by I3LaZeN

Lowered on MSS Automotive adjustable springs.

Are these oem’s or reps?

[Neusser]

Originally Posted by peteinpa

706m wheels , stock height.

Thread winner.

I would put these on my 540 if TüV weren't such a pain in the ass here.

[tpires96]

Originally Posted by Junebug85

Here's my 540i lowered on MSS Springs with 20" BBS CI-R wheels...

Hey bro! What are the wheel specs front and rear with the offset and all included, thanks! Also what tire size you were running. Thanks man

[Junebug85]

Originally Posted by tpires96

Hey bro! What are the wheel specs front and rear with the offset and all included, thanks! Also what tire size you were running. Thanks man

Wheels and Tyres are OE sizes...
8x20 et26
9x20 et38
245/35/20
275/30/20
Fronts have a 10mm spacer (making the wheels et16)
Rears have a 15mm spacer (making the wheels et23)

[drewG30]

Originally Posted by PetieD 7

20" silver polished Vossen HF-4T wheels w/ red center caps in stock height at this point.

how can i find or specify the black part of the bumper to buy one?

[drewG30]

Originally Posted by I3LaZeN

Lowered on MSS Automotive adjustable springs.

how is the adjustment done?

[drewG30]

what are disadvantages to lowering? what are lowering options?

[PetieD 7]

Originally Posted by drewG30

how can i find or specify the black part of the bumper to buy one?

The accessory that you’re referring to is: gloss black front spiltter. It’s made by Maxton Design from Europe. Below are the authorized online retailers in the US and Canada.

CAN:
https://maxtondesign.ca/products/bmw...3fcbfb8e&_ss=r

USA:
https://maxtondesignusa.net/products...cce29d82&_ss=r

[LAZY.G30]

Vossen HF-5 stock suspension

[ActavisDreams]

H&R Springs on 18's for the winter.
After seeing these setups I'm definitely getting some 20's in the spring.

[rsc1]

Aodhan AFF9
255/35 20x9 +30 F
285/30 20x10.5 +35 R

Fronts were slightly tucked, added 5mm spacer to give +25 effective offset, now pretty flush. Lowered on Dinan springs.

[BenjaminPerkins]

Originally Posted by rsc1

Aodhan AFF9
255/35 20x9 +30 F
285/30 20x10.5 +35 R

Fronts were slightly tucked, added 5mm spacer to give +25 effective offset, now pretty flush. Lowered on Dinan springs.

How much is the car lowered by ? This car looks AMAZING

[rsc1]

Originally Posted by BenjaminPerkins

How much is the car lowered by ? This car looks AMAZING

Thanks, the Dinan springs are a 7/8" drop.

[badseedtech]

Originally Posted by rsc1

Aodhan AFF9
255/35 20x9 +30 F
285/30 20x10.5 +35 R

Fronts were slightly tucked, added 5mm spacer to give +25 effective offset, now pretty flush. Lowered on Dinan springs.

Damn man, this is razor sharp. 🫡

[Neusser]

Originally Posted by drewG30

what are disadvantages to lowering? what are lowering options?

They can throw off your suspension geometry, particularly where your control arms are concerned. Bump steer and increased body roll are common maladies.

Lowering another cm is probably ok if you value proper handling, but I would be cautious going lower. The M5 sits about a cm lower, but it also has a number of different components on the front end, so very difficult to say unless you know geo specs of the stock setup, and what the tolerances are with regard to the roll center.

I have never driven a casually lowered car that drove better than a stock sport suspension. There are usually multiple components that need to be changed in order to see a real improvement, holistically speaking.

That said, many are just after a certain look.

[afakem5]

Backs rubbing but here’s 20inch wheels, stock height
