[ejlover06]

Originally Posted by menace33

This is current value:
0E, ED, 90, 0A, E1, EE, 0D, 5C, 00, 00, 00, 10, 00, 0E, 00, 0E, DC, 80, 80, E0, EE, 5E, DE, 0D, 90, 0C, D0, A0, 0C, 0D, 00, EA, ED, D0, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, DD, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, FF, 11, 56, 45, 05, 50, 00

Try this:

[menace33]

Originally Posted by ejlover06

Try this:
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF

I'll give it a go when I get to Serbia. Now I am in Croatia where everything works. Thanks

[menace33]

This last code you've sent me works like a charm!

[ejlover06]

Originally Posted by menace33

This last code you've sent me works like a charm!

I'm glad it worked

[Mrempty84]

Dear fellows!

Thanks, for sharing you ideas and the way you trying to achieve it

My bmw g30 my2019 doesn't have KAFAS, so i use FSC code, to activate SLI from navigation map (I used sli emulator from ali).

nowdays i try to activate manual SLI assist, i did this codings and have Speed Limit Assist in NBT and can activate it, but nothing happens and i don't have limit assist at dashboard.

Here's my coding:

DSC3:
C_EDP_vorhanden = nicht_vorhanden -> vorhanden
C_EDP_Land_Aktiv = F9, DC, 00, 00 -> all FF
C_SLA_Variante = kiene -----> dcc [01]
C_vSLI_Land_aktiv = UNK_PARAM_1 (FB, DF, 83, C0) -> all FF
C_VZA_Funktion_Land_aktiv = UNK_param_1 (FB, DF, 83, C0) -> all FF
C_VZA_Funktion - false --> true



BDC_BODY2
3420 DG_3420, 14 24 STRECKEN_VERLAUF --- aktiv
PIA_DEFAULT_UEBERNAHME_GESCHWINDIGKEIT aktiv
UEBERNAHME_GESCHWINDIGKEIT aktiv

sas2

C_EDP_vorhanden = false --------------------> true
C_EDP_Land_Aktiv FB, DC, 00, 00 ---> all FF
C_EDP_Vorausschau_aktiv = UNK_param_1 FB, DF, 83, C0 ---->> all FF
C_EDP_SLI_aktiv = FB, DF, 80, 00 ---->> all FF
C_EDP_Anzeige_Zusatztexte: = true
C_vSLI_Land_Aktiv UNK_param_1 FB, DF, 83, C0 -->> all FF
C_vSLI_Funktion - false --> true

C_EDP_Laendersteuerung_Konfiguration Voraus aus matrix, sli immer aktiv---->Vorausschau immer aktiv, SLI immer aktiv
C_ISA_vorhanden false ->> true
C_VZA_Funktion_Land_aktiv UNK_param_1 FB, DF, 83, C0 -->> all FF

dkombi

LDM_ISA_ENABLE nicht_aktiv ---> aktiv
LDM_TIP_ENABLE nicht_aktiv ---> aktiv
LDM_VORAUSSCHAU_ENABLE nicht aktiv [01]---> not change
LDM_VORAUSSCHAU_sli_ENABLE - nicht_aktiv--> aktive
HMI_ECO_TIPP_GESCHWINDIGKEIT_KI_ENABLE aktiv

nbt

slamanuel - nicht ----> gen_1
AUTOTEMPOMAT - nicht aktiv --->gen1
AUTOLIMITER - nicht aktib ----> gen1
HUD_VZA - nicht - > aktiv
KI_DISP_CB_STRECKENUEBERSICHT - nicht -> aktiv
STRECKENVERLAUF aktiv [01]
VORAUSSCHAU gen 1
VOFFSET gen1


After that i have an error in SAS:

Message (traffic sign recognition, 258.1.4) missing, recipient SAS, sender KAFAS

I think i missed something, couse SAS recieve message from KAFAS, but cannot recognize it.
Or it's not possible to activate manual SLI assist without KAFAS module?

[Wojti_]

hi
who can write correct coding for speed limit activation in G30 2019 (means MGU an live cocpit). Of course kafas4 is in the car. I ordered fsc, and i just looking for coding. I have some from many pages, but all diffrent and diffucult check what is true.
thanks in advance

Edit 23-09-2021:
I added SLI_NPI to car - some photoes added

[The-Traveler]

Originally Posted by ejlover06

DSC: C_EDP_Land_aktiv Werte=FF, FF, FF, FF
DSC: C_vSLI_Land_aktiv Werte=FF, FF, FF, FF
DSC: C_SWA_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_vSLI_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_Vorausschau_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_SLI_aktiv Werte=FF, FF, FF, FF

also added Germany car options via FDL coding such as:
DSC: C_VFA_Funktion
SAS10: C_SWA_Vorhanden
KAFAS: VFW_AVAILABLE
KAFAS: WWA_ENABLE
BDC_BODY2: VCM_COUNTRY (mine was ECE)
KOMBI: LAENDERAUSFUEHRUNG (mine was Sonstige)
RS: C_SWW_Enable_LaneWidthAdjustmentByKAFAS

I have a G30 with the same features as you, but no SAS module. Here's what esys shows me. Do I need to add a VO code in order for SAS to appear?

ACSM5
AMP_TOPHE
ATM
BDC_BODY2
BDC_GW2
DKOMBI2
DME_BAC2
DSC3
EGS
EME3
FLM
FLM
FRR2
FZD2
GWS2
HKEM2
HU_NET2
ICAM3
IHKA4
KAFAS4
LMV2
OBC
RS
SM2
SM2
SME217
SPM
SPM_S
TFM2
USS
VSG
ZBE4

[ejlover06]

Originally Posted by The-Traveler

I have a G30 with the same features as you, but no SAS module. Here's what esys shows me. Do I need to add a VO code in order for SAS to appear?

ACSM5
AMP_TOPHE
ATM
BDC_BODY2
BDC_GW2
DKOMBI2
DME_BAC2
DSC3
EGS
EME3
FLM
FLM
FRR2
FZD2
GWS2
HKEM2
HU_NET2
ICAM3
IHKA4
KAFAS4
LMV2
OBC
RS
SM2
SM2
SME217
SPM
SPM_S
TFM2
USS
VSG
ZBE4

Those are the hardware list of ECUs you have. VO code won't magically install a missing ECU on the car

[The-Traveler]

Originally Posted by ejlover06

Those are the hardware list of ECUs you have. VO code won't magically install a missing ECU on the car

Lol I know, but VO codes show/hide modules in esys, if they exist.

[qevalla]

Hello guys
Is anyone of you having an issue with Driving Assistance Affected after pressing the button Cruise Control with Distance Control in the steering wheel. I have changed the SLINPI values to 00 and FF, it reads the signs very good and also the Distance Control works good but as soon as I press the button in steering wheel it shows the Driving Assistance Affected in head unit.
Thank you!

[sstyle]

Who knows how to increase additional speed value from 15km/h to 20km/h? https://g30.bimmerpost.com/forums/sh...1#post28995431

[BMW5and7]

Just revisiting this subject: Has anyone been able to provide a working code path for <2019 G30 with idrive 6 for the speed-adjust to work?

[mrgicm]

Originally Posted by The-Traveler

Lol I know, but VO codes show/hide modules in esys, if they exist.

That is not correct

[The-Traveler]

Originally Posted by BMW5and7

Just revisiting this subject: Has anyone been able to provide a working code path for <2019 G30 with idrive 6 for the speed-adjust to work?

Same question.

[MASAMI]

I'm using a 2017 G30 523d.
I got my FSC code for SLI activation.
The data sent

(xxxxxxx is the VIN code of your vehicle)
e.g. xxxxxxx_007E0001.xml
e.g. xxxxxxx_007E0001.der
e.g. xxxxxxx_007E0001.fsc

Are the following FSC installation parameters correct?
Diagnostic address 0x5D
Application number 126
Base variant KAFAS4
upgrade index 1

[uakcay]

Can you share fsc for sli?
g30 2017

WBAJA5C39HG456261

[mrpingu]

Originally Posted by ejlover06

And "Assist" word added to the oem "Limit" function. And car suggests and update with a green arrow and green circle around speed limit in cluster and HUD like this:


It should do the same for the cruise control speed. But it is not

Then after the last codes I've shared, that menu in the first photo converted into this (now there is 1 more option added as "Update manually"; but only last one "show speed limits" is selectable) (still only top speed limit update works):
[/IMG]

I want the car to update the cruise control speed according to signs read by KAFAS/or map data as it does with the top speed limit.

Did you manage to find out about this, to make the CC also take over the speed like the LIM button can?

[micvite]

Originally Posted by mrgicm

You need FSC code to activate SLI for Kafas4. If you need fsc for SLI, Wrong Way Assist or Front end collision pm me.

are you still able to get wwa fsc codes? I'd like one for f90 m5

[lawrence.eka]

Originally Posted by ejlover06

My G30 (ECE) has 5AS so it has KAFAS4, Dynamic Cruise Control (DCC)(no front radar) and we've retrofitted SLI&NPI and they work without any problems. But there are 3 more features that comes with (depends upon) SLI actually:

ISA: updates the adjusted speed of cruise control according to speed signs read by SLI.
EDP: updates the adjusted speed of speed limiter according to speed signs read by SLI.
VZA (VORAUSSCHAU): warns the driver of an approaching speed limit change along the road to let the gas pedal off. So when the car arrives to the place where the speed limit decreased cars speed will be equal to that limit automatically by deceleration (so you won't use breaks and spend unnecessary gas).
Additional Sign:Which signs it refers I don't know but KOMBI should display the upcoming signs (in white color) probably as the part of VZA. Also some cars show stop signs and so on. This also doesn't work at my G30

My car came with 8TD, so to make SLI work it has been removed and I had to modify COUNTRY_SLINPI_MODE in KAFAS because it remained at (---) icon. After that SLI and NPI works flawlessly

Even ISA, EDP, VZA related codes seems active on all modules they don't work. So I've generated CAFD files by using Coding Verification by changing my cars VO list (removed 5AS and added 5AT). I've compared all 32 files and found about 90 parameter changes.

I've modified ISA, EDP and VZA related ones and I have a "Speed Limit Assistance" Menu added to iDrive settings under vehicle settings as seen below:



Last sentence means: "It's only available as a restricted feature in this country". After that casual "Limit" function (which limits your max speed to set value) changed into "Limit Assist" (which asks to update your currently set max speed limit automatically to actual limit on the road +- a buffer value you've selected on the idrive menu). It can be seen below:



Problem is Cruise Control icon didn't changed into "Assist + cruise logo" and it doesn't asks to set limit according to SLI
No matter which parameters I've changed I couldn't make it work. I've tried every parameter from 5AT option (except iBrake and ACC related ones) but it never activated.

I even activated ISA related parameters (which 5AT even left inactive) no change.. Also ISA doesn't seem to be supported by G30 according to E-Sys as seen below but I've also set these to activce:


I also changed land restriction parameters into these since their current values doesn't work (which are same for Germany cars):
DSC: C_EDP_Land_aktiv Werte=FF, FF, FF, FF
DSC: C_vSLI_Land_aktiv Werte=FF, FF, FF, FF
DSC: C_SWA_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_vSLI_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_Land_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_Vorausschau_aktiv Werte=FF, FF, FF, FF
SAS: C_EDP_SLI_aktiv Werte=FF, FF, FF, FF

also added Germany car options via FDL coding such as:
DSC: C_VFA_Funktion
SAS10: C_SWA_Vorhanden
KAFAS: VFW_AVAILABLE
KAFAS: WWA_ENABLE
BDC_BODY2: VCM_COUNTRY (mine was ECE)
KOMBI: LAENDERAUSFUEHRUNG (mine was Sonstige)
RS: C_SWW_Enable_LaneWidthAdjustmentByKAFAS

yet nothing (still says function is limited only in my country).


To conclude Limit Assistant has been activated, but cruise control speed "assistant mode" to update CC speed doesn't.

Also I've never seen upcoming speed sign icon (white color next to current speed limit in the KOMBI) and anything related with VZA (gas icon, arrows etc.)


So I'm about to abandon this project. But I know it must work. I think car sees that it's currently located in Turkey and deactivates Cruise Control Assist. Because I'm sure that I've activated all the parameters required for this function. So I have to find a code to lift restrictions for countries like the COUNTRY_SLINPI_MODE for the SLI activation.

I'd appreciate any suggestions

Hi, ejlover06 I'm interested in knowing if SLI can be activated in my car. I just PM-ed you. Thanks before.

[g31mit]

FDL coding without any FSC.
I have only KAFAS4MID, no front radar.
