G30 Speed Limit Info

larry_bml · 11-04-2019, 04:48 AM

What is the right coding for an G series with official SLI FSC bought?
Can someone help me?

Thank you.

kubax86 · 11-04-2019, 08:53 AM

Quote:

Originally Posted by larry_bml

What is the right coding for an G series with official SLI FSC bought?
Can someone help me?

Thank you.

It is done by FDL coding.

larry_bml · 11-04-2019, 09:14 AM

Quote:

Originally Posted by kubax86

It is done by FDL coding.

Do you have these fdl codings needed?

mrgicm · 11-04-2019, 02:05 PM

Quote:

Originally Posted by larry_bml

Do you have these fdl codings needed?

You can just VO code

larry_bml · 11-04-2019, 03:10 PM

I can, but I heard that EVO can go in component protection if something is not original in VO. That is why I asked about FDL lines.

kubax86 · 11-09-2019, 11:56 AM

Quote:

Originally Posted by mrgicm

You can just VO code

You can’t VO code SLI in G30.
EVO won’t go into CP when coding with original FA.

Kolbenmoor · 06-17-2020, 12:21 AM

Does anybody know the right coding for SLI?

Shatter · 06-17-2020, 05:55 AM

Quote:

Originally Posted by Kolbenmoor

Does anybody know the right coding for SLI?

Code:

HU
SPEEDLIMIT_INFO: aktiv [01]

KAFAS
NPI_ENABLE: initwert [01]
SLI_ENABLE: initwert [01]

KOMBI
CB_TACHOZEIGERBAND: aktiv [01]
HUD_NO_PASSING_ENABLE: aktiv [01]
HUD_SPEED_LIMIT_ENABLE: aktiv [01]
NO_PASSING_ENABLE: aktiv [01]
PIA_HUD_SLI: aktiv [01]
PIA_HUD_SLI_NPI: aktiv [01]
PIA_HUD_SLI_PORTIERUNG: aktiv [01]
PIA_HUD_VSLI: aktiv [01]
PIA_SLI_NPI: aktiv [01]
PIA_TACHOZEIGERBAND: aktiv [01]
PIA_TACHOZEIGERBAND_PORTIERUNG: aktiv [01]
RCOG_TRSG_APPL: aktiv [01]
RCOG_TRSG_TIMEOUT: aktiv [01]
SPEED_LIMIT_ENABLE: sli [01]
TACHOZEIGERBAND_ENABLE: aktiv [01]
SLI_PERMANENT_ENABLE: aktiv [00]
ADDITIONAL_SIGN_ENABLE: aktiv [00]

mrgicm · 06-17-2020, 06:11 AM

You need SLI FSC for Kafas to enable SLI.

vr · 09-08-2020, 03:08 PM

Quote:

Originally Posted by Shatter

Code:

HU
SPEEDLIMIT_INFO: aktiv [01]

KAFAS
NPI_ENABLE: initwert [01]
SLI_ENABLE: initwert [01]

KOMBI
CB_TACHOZEIGERBAND: aktiv [01]
HUD_NO_PASSING_ENABLE: aktiv [01]
HUD_SPEED_LIMIT_ENABLE: aktiv [01]
NO_PASSING_ENABLE: aktiv [01]
PIA_HUD_SLI: aktiv [01]
PIA_HUD_SLI_NPI: aktiv [01]
PIA_HUD_SLI_PORTIERUNG: aktiv [01]
PIA_HUD_VSLI: aktiv [01]
PIA_SLI_NPI: aktiv [01]
PIA_TACHOZEIGERBAND: aktiv [01]
PIA_TACHOZEIGERBAND_PORTIERUNG: aktiv [01]
RCOG_TRSG_APPL: aktiv [01]
RCOG_TRSG_TIMEOUT: aktiv [01]
SPEED_LIMIT_ENABLE: sli [01]
TACHOZEIGERBAND_ENABLE: aktiv [01]
SLI_PERMANENT_ENABLE: aktiv [00]
ADDITIONAL_SIGN_ENABLE: aktiv [00]

I did it on my 530d 2017, updated recently at the dealership, I don't have drive assistant so the option wasn't there since the beginning but I do have the kafas camera (at least I see 'conneted drive' and a camera in the windshield, I suppose for the high beam assist that I have). I also have a ECU called KAFAS4 so I supose to have the HW.

I coded the above, but I get only -- and -- both for SLI and NPI.

I am afraid i need some kind of FSC code to load in the KAFAS ECU to work and send the signal?? what the h... I am out of ideas...

help

vr · 09-08-2020, 03:13 PM

desperate, I saw there is an option to set how the SLI is referenced, Camera only 0, Fusion Camera and GPS 1, GPS only 2 ... I have it on fusion, thiking to try 2... but would be less effective almost useless

kubax86 · 09-08-2020, 03:50 PM

Quote:

Originally Posted by vr

I did it on my 530d 2017, updated recently at the dealership, I don't have drive assistant so the option wasn't there since the beginning but I do have the kafas camera (at least I see 'conneted drive' and a camera in the windshield, I suppose for the high beam assist that I have). I also have a ECU called KAFAS4 so I supose to have the HW.

I coded the above, but I get only -- and -- both for SLI and NPI.

I am afraid i need some kind of FSC code to load in the KAFAS ECU to work and send the signal?? what the h... I am out of ideas...

help

Yes, of course.
You need FSC for SLI.

Biliardiere · 09-20-2020, 09:54 AM

Quote:

Originally Posted by kubax86

You can’t VO code SLI in G30.
EVO won’t go into CP when coding with original FA.

All right! I solved it with bimmercode. Here's how I did it. Thanks anyway hello

Fari84 · 09-20-2020, 04:32 PM

Quote:

Originally Posted by Biliardiere

All right! I solved it with bimmercode. Here's how I did it. Thanks anyway hello

Hello!
How can i do it with bimmer code?
Can anyone help me?

I already reach to (--) on cluster and HUD. What is missing?

Thank you

kubax86 · 10-18-2020, 06:02 PM

Quote:

Originally Posted by Fari84

Hello!
How can i do it with bimmer code?
Can anyone help me?

I already reach to (--) on cluster and HUD. What is missing?

Thank you

Yes, you need 11F activation code. Then apply it using E-Sys.

ejlover06 · 11-03-2020, 05:03 AM

Quote:

Originally Posted by hurricane876

Hi Guys,

Anybody know that is the "clock" icon next to the speed limit info?

I checked the user manual but no any mention...

Thanks

Have you figure out the clock icon yet?

I also additionally activated the speed limit assist to change the speed limit functions value set. Bu I couldn't figure out to update cruise control speed automatically yet. Any ideas?

GaSelle · 11-04-2020, 02:26 AM

Quote:

Originally Posted by ejlover06

Have you figure out the clock icon yet?

I also additionally activated the speed limit assist to change the speed limit functions value set. Bu I couldn't figure out to update cruise control speed automatically yet. Any ideas?

I´m pretty sure that it refers to a time restriction in the shown limit. I.e. there is a 30 km/h limit from 6-8 and 16-18.

ejlover06 · 11-04-2020, 06:46 AM

Quote:

Originally Posted by GaSelle

I´m pretty sure that it refers to a time restriction in the shown limit. I.e. there is a 30 km/h limit from 6-8 and 16-18.

It never shown on my car. Probably it's reading data from the navigation and that data is not available on my car

GaSelle · 11-05-2020, 12:30 AM

Quote:

Originally Posted by ejlover06

It never shown on my car. Probably it's reading data from the navigation and that data is not available on my car

It depends on which country you're in, I think. I´ve seen it when driving in Germany, but never in Denmark.

leomi13 · 11-17-2020, 06:18 AM

Quote:

Originally Posted by Biliardiere

All right! I solved it with bimmercode. Here's how I did it. Thanks anyway hello

hi Biliardiere, you changed just these value?
i'ma also from Italy ;D

mrgicm · 11-17-2020, 03:29 PM

Quote:

Originally Posted by larry_bml

I can, but I heard that EVO can go in component protection if something is not original in VO. That is why I asked about FDL lines.

Evo will go into Component Protection only if it detects another VIN, which can also be removed.

Biliardiere · 11-22-2020, 01:18 PM

Quote:

Originally Posted by leomi13

hi Biliardiere, you changed just these value?
i'ma also from Italy ;D

Ci vuole il codice fsc per avere SLI,io dovevo solo attivare il cartello di divieto 🚫 sorpasso.Ciao
